4-5 CrossPoint Plus Matrix Switchers • Programmer’s Guide
Command/response table for SIS commands (Cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
List all sync (DSVP) LS Input•Horz.•Vert.
X1 •• X4 • X4
thru
X1 •• X4 • X4
Example: LS Input•Horz.•Vert.
01••031.50•060.00
Input 1 (H) 31.5 kHz (V) 60 Hz
thru thru
16••031.50•060.00 Input 16 (H) 31.5 kHz (V) 60 Hz.
I/O Grouping
Write input grouping Esc i X5 … X5 IWrt One X5 entry for each input.
Example: Esc i42…33 IWrt In1-Grp 4, In2-Grp 2,…In16-Grp 3.
Write output grouping Esc o X5 … X5 OWrt One X5 entry for each output.
Read input grouping Esc I GrpI X5 … X5 One X5 entry for each input.
Read output grouping Esc O GrpO X5 … X5 One X5 entry for each output
RGB delay
Set RGB delay X6 * X2 D Out X2 •Dly X6
Example: 7*13D Out13•Dly07 Sets the RGB interval for switches
to output 13 to 3.5 sec. (7x0.5 sec.).
Read RGB delay X2 D Out X2 •Dly X6
Example: 13D Out13•Dly05 Output 13 interval is 2.5 sec. (5 x
0.5 sec).
Audio input gain and attenuation
Set audio input gain to +dB value X1 * X7 G In X1 •Aud= X9
Example: 1*2G In01•Aud=+02 Set input 1 audio gain to +2dB.
Set audio input attenuation to -dB value X1 * X8 g In X1 •Aud= X9
Increment gain up X1 {G In X1 •Aud= X9
Example: 5 {G In05•Aud=+03 Audio input 5 level incremented
from +2dB to +3dB.
Decrement gain down X1 }G In X1 •Aud= X9
Example: 7 }G In07•Aud=-09 Audio input 7 level decremented
from -8dB to -9dB.
Global presets
Save current configuration as preset X11 , Spr X11 Command character is a comma.
Example: 9, Spr09 Save current ties as preset 9.
Recall a preset X11
.
Rpr X11 Command character is a period.
Example: 5
.
Rpr05 Recall preset 5, which becomes
the current configuration.
