Play Local Content
The SMD 101 has internal memory reserved for local content. Local content is viewed
from the browser
Files tab. A typical folder structure for the internal memory is
shown at right.
NOTES:
• The media folder is currently reserved for future use. Do not put user
content files in the folder.
• TMP folders are not accessible.
Content (up to 175 MB total) can be transferred directly to the SMD 101 from a
computer on the same network using an FTP client such as Filezilla, a free FTP
program available here:
https://filezilla-project.org/download.php?type=client
Download and install the FileZilla program.
After installation, run the program.
1. From the toolbar select File>Site Manager. The Site Manager dialog
opens (see right).
2. Enter the SMD 101 IP address in the Host: field.
3. Enter 22022 in the Port: field.
4. Select SFTP in the Protocol: drop-down list.
5. Select Normal from the Logon Type: drop-down list.
6. Enter admin in the User: field.
7. Enter the SMD 101 admin password if one is set. Otherwise leave the
Password: field blank.
8. Click Connect to start the connection routine.
Filezilla establishes a connection with the SMD 101 at the IP address in the
Host: address and logs in.
Filezilla defaults to the root of the SMD 101 local memory (on the right in the figure
below) and shows all files and folders stored in the user file system.
In the example below, a file is uploaded from the PC to the SMD 101
Clips folder
using the right-click menu.
C:\Users\Videos\MediaShare Remote site: Local site:
PC file uploads to:
PC Folders and Files SMD 101 Folders and Files
General
Host:
Protocol:
Logon Type:
User:
Password:
Account:
Comments:
192.168.193.165 22022
SFTP-SSH File Transfer Protocol
Normal
admin
*****
Port:
audio
Audio-File-1.m4a
clips
Video-clip-1.mp4
images
nortxe-backup
shares
MediaShare
/
Files
Browser
