PPS 35 • Installation Guide (Continued)
Extron USA Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.8 50.1000
+1.714.491.1517 FAX +1.919.8 50.1001 FAX
Extron Europe
+800.3987.6673 (Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX Extron India
1800.3070.3777 (Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
© 2013 Extron Electronics — All rights reserved. All trademarks mentioned are the property of their respective owners.
www.extron.com
L
R
DO NO T
GR OUND OR SHO RT
SPEA KER
OUT PUT S
4/8 Ω
3A M AX POWER
12V
HD MI
1/2
SIG
LINK
SIG LINK 3/4
INPUT S
OU TPUT
AU DIO OU T
PV S 405
SA IP
AM PLI FIE D AUD
IO OU T
PAGI NG
SE NSO R
PV T IN
PV T IN
L
R
AU X
OVER PV
T REM OTE
VOICE
LIFT
LAN 1
LAN 2
LAN 3
INPUT 5
+V
L
R
RS-232
Tx Rx IR
S G
G
Ceiling Mounted
Paging Speaker
PPS 35
Priority Page Sensor
(installed on Speaker
Front Grille)
Classroom Admin Building
To Classroom
Paging Speakers
Sensor
Output
Paging
Sensor
Input
Extron
PVS 405D
PoleVault Switcher
Plenum cable
Front Grille)
PPS 355
Priority Page Sensor
(installed on Speaker
Front Grille)
Extron
FF 120
Flat Field Speakers
Testing and Adjustment Procedure
1. Turn the program audio on.
2. Initiate a page from the PA system. The program audio is muted while the PA
system broadcast occurs, and restored when the PA broadcast ends.
3. If program audio is not muted during a PA broadcast,
turn the Paging Sensitivity adjustment knob on the
front panel of the PVS 405D clockwise.
4. If program audio is muted without a page occurring,
turn the Paging Sensitivity adjustment knob on the
PVS 405D counterclockwise.
5. To prevent the switcher’s audio from being
restored prematurely due to pauses by the
announcer, a time delay may be set from 1 to 8 seconds via SIS commands or
configuration software. Default is 3 seconds. See the PVS 405D User Guide for
SIS commands.
NOTE: To complete the system installation, see the PoleVault Digital System
Installation Guide (featuring the PVS 405D switcher), available online at
www.extron.com .
PVS 405D
POLEVAULT SWITCHER
AUDIO LEVEL ADJUST
PEAK
NORMAL
SIGNAL VOICELIFT
PAGING
SENSOR
SENSITIVITY
AUDIO LEVEL ADJ
PEAK
NORMAL
SIGNAL VOICELIFT
J
Figure 9. Paging Sensitivity
Adjustment Knob
Figure 10. Typical PPS 35 Application Using the PVS 405D Switcher
68-2468-01
Rev A
10 13
