LED Indicator
A multi-color LED on the top of the enclosure indicates its operation:
LED Color Description
Amber AC power is on.
Green A PoE device is connected and drawing power.
Blinking A PoE device is drawing excessive current.
Reference
Model Part Number Power Output Connections
PS PoE 70-828-01
(PW182RB4800F01) 17 watts,
+48 VDC,
0.35 A max. Ethernet: Dual RJ-45
AC Power: IEC
68-2015-50
Rev. A
02 11
PS PoE Power Supply Kit
The Extron PS PoE Kit can be used to provide power over Ethernet (PoE) to network-connected products that require an 802.3af compliant power
inserter, or to replace PoE power supplies of the same capacity.
To connect the power supply:
1. Connect the PoE device cable to the Pwr LAN-Out port.
PWR LAN-OUT LAN-IN
To Local Area Network (LAN) To PoE-powered Device
Power over Ethernet (PoE) Power Supply Connection
2. Connect the network cable to the LAN-In port.
3. Connect AC power to the PoE power supply.
CAUTION: See the Extron Safety and Regulatory Compliance Guide, part number 68-290-01, for safety instructions.
LED Indicator
A multi-color LED on the top of the enclosure indicates its operation:
LED Color Description
Amber AC power is on.
Green A PoE device is connected and drawing power.
Blinking A PoE device is drawing excessive current.
Reference
Model Part Number Power Output Connections
PS PoE 70-828-01
(PW182RB4800F01) 17 watts,
+48 VDC,
0.35 A max. Ethernet: Dual RJ-45
AC Power: IEC
68-2015-50
Rev. A
02 11
PS PoE Power Supply Kit
The Extron PS PoE Kit can be used to provide power over Ethernet (PoE) to network-connected products that require an 802.3af compliant power
inserter, or to replace PoE power supplies of the same capacity.
To connect the power supply:
1. Connect the PoE device cable to the Pwr LAN-Out port.
PWR LAN-OUT LAN-IN
To Local Area Network (LAN) To PoE-powered Device
Power over Ethernet (PoE) Power Supply Connection
2. Connect the network cable to the LAN-In port.
3. Connect AC power to the PoE power supply.
CAUTION: See the Extron Safety and Regulatory Compliance Guide, part number 68-290-01, for safety instructions.
