Commands – Extron Electronics PVS 204SA Plus Installation Addendum User Manual
Page 4
SIS Command/Response Table
Command
ASCII (Telnet)
(host - switcher)
Response
(switcher to host)
Video Configuration
Set the video signal type
X!* X2# \
TypX!= X2#]
View the video signal type
X! \
TypX!= X2#]
Status Commands
View all input status
LS
Frq= X2$* X2$* X2$* X2$]
View paging sensor status
42S
Sts42*X#]
Mic Talk-over Threshold
Adjust talk-over threshold
2* X2% #
ThrX2%]
Decrement threshold
-* 2#
ThrX2%]
Increment threshold
+* 2#
ThrX2%]
View mic threshold
2#
ThrX2%]
Program Audio Ducking Level
Adjust audio ducking level
58 * X2^#
AdlX2^]
Increment audio ducking
+* 58#
AdlX2^]
Decrement audio ducking
-* 58#
AdlX2^]
View audio ducking
58#
AdlX2^]
Set Lineout Mode
Set lineout to variable
55*1#
LineOut*X2&]
Set lineout to fixed
55*2#
LineOut*X2&]
View lineout mode
55#
LineOut*X2&]
VCM Mute Mode
Mute all (Aux/Mix and program) audio
74*1#
VCMX2*]
Mute Aux/Mix audio (program goes through)
74*2#
VCMX2*]
Mute program audio (Aux/Mix goes through)
74*3#
VCMX2*]
VCM mute mode status
74#
VCMX2*]
Paging Sensor Delay
Set paging sensor delay
75 * X2(#
PageDly*X2(]
View paging sensor delay
75#
PageDly*X2(]
]
= CR/LF (carriage return/line feed) (hex 0D 0A)
}
= CR (no line feed)
•
= Space
E
= Escape key
X! = Input numbers 1 through 4, and 7;
0 = all outputs muted (both audio and video)
1 and 2 = RGB inputs (also 1 and 2 in RGB/VGA group)
3 and 4 = Composite video inputs in Single Switch Mode.
In Separate Switch Mode, composite video inputs are
identified as 1 and 2 in the Composite Video/Vid Group
7 = Aux/Mix input (not applicable with audio and video
breakaway commands)
X# = Status
0 = Off
1 = On
X2# = Video type (inputs 3 and 4 only)
1 = Composite video (default)
2 = RGB
X2$ = Video signal status
1 = A video signal present
2 = No video signal detected
X2% = 0 to 15 microphone talk-over threshold level range,
default = 8
X2^ = 0 to 30, program audio ducking level in talk-over mode,
default = 6
X2& = Lineout status
1 = variable (default)
2 = fixed
X2* = VCM mute mode status
1 = mute all (Aux/Mix and program) audio (default)
2 = mute Aux/Mix audio (program goes through)
3 = mute program audio (Aux/Mix goes through)
X2( = Paging delay on 1 second steps; default = 0 (disabled),
1 = 1.0 second, 2.0 = 2 second, ..., 8 = 8.0 second
PVS 204SA Plus specific symbol definitions
Symbols (X/ values) defined here are used throughout the command/response table below.
The symbols represent variables in the switcher-initiated messages and the command/response table fields.
SIS
™
Commands
For all PoleVault device specifications, optional accessories, and part numbers, visit
www.extron.com
