Extron Electronics P-2 DA2 Plus User Guide Rev. D User Manual

P/2 da2 plus, User’s guide

background image

User’s Guide

Extron Electronics, USA

1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
Fax 714.491.1517

Extron Electronics, Europe

Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax +31.33.453.4050

Extron Electronics, Asia

135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax +65.6383.4664

Extron Electronics, Japan

Kyodo Building
16 Ichibancho
Chiyoda-ku, Tokyo 102-0082 Japan
+81.3.3511.7655
Fax +81.3.3511.7656

www.extron.com

© 2006 Extron Electronics. All rights reserved.

Sync

Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs
Input level ..................................... 3 V to 5 Vp-p
Output level .................................. TTL: 5 Vp-p, unterminated
Input impedance .......................... 510 ohms
Output impedance ....................... 50 ohms
Max. propagation delay ............. 60 ns
Max. rise/fall time ....................... 4 ns
Polarity .......................................... Positive or negative

General

External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, 4.5 watts,

external, autoswitchable;
to 9 VDC, 1 A, regulated

Power input requirements ......... 9 VDC, 0.2 A
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

Rack mount ................................... No
Enclosure type .............................. Plastic
Enclosure dimensions ................. 1.4" H x 5.0" W x 3.3" D

3.6 cm H x 12.7 cm W x 8.4 cm D
(Depth excludes connectors.)

Product weight ............................. 1.6 lbs (0.7 kg)
Shipping weight .......................... 3 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe

Transit Association)

Listings .......................................... UL, CUL
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.

Distribution Amplifier

P/2 DA2 Plus

68-362-01 Rev. D

01 06
