Description – Extron Electronics P-2 DA2xi User Guide Rev. A User Manual
Page 4
P/2 DA2xi • Installation and Operation
1
Description
The P/2 DA2xi is a high performance one input, two output
distribution amplifi er that accepts video input from a VGA-
QXGA compatible PC and distributes that signal to separately
buffered outputs. The output can be extended with Extron
MHR cables up to 250' in length (XGA resolution signal).
The P/2 DA2xi routes all video ID bits to its local monitor
output to allow for automatic resolution selection by DDC1 and
DDC2 (plug and play cards and projector).
Features
• Power LED — useful in system troubleshooting
• Impedance DIP switches — for solving laptop compatibility
problems and refl ection problems due to long cable runs
• Bandwidth — 300 MHz (-3 dB) RGB video bandwidth
maintains signal integrity
• ID bits pass-through — routes ID bits to the local monitor
output to allow automatic scan rate selection by DDC
