Software Control
This section describes the control software for the MVC 121 Plus, including:
• Software Control
• Windows-based Program Control
• DSP Configurator Program
Software Control
The MVC 121 Plus can be controlled using the DSP Configurator software, SIS commands
through HyperTerminal or DataViewer.
The MVC has the following connection options:
• RS-232 — One single stack 6-pole, 3.5 mm captive screw connector is used for
bidirectional RS-232 (±5 V) serial control.
See
Rear Panel Features on page 4, for additional details on connecting the RS-232
port.
• USB 2.0 — A Mini B-type USB connector located on the front panel provides
high-speed USB 2.0 connectivity to a host computer, backward compatible to 1.0.
Windows-based Program Control
The DSP Configurator control program is compatible with Windows 2000 and later
Windows versions, and provides remote control of the input gain and attenuation, output
volume output adjustment, and other features.
DSP Configurator can control the MVC 121 Plus via any of the two control ports, RS-232
or USB.
Updates to this program can be downloaded from the Extron website at
www.extron.com.
Installing the DSP Configurator Program
The program is contained on the Extron Software Products disc.
Install the software as follows:
1. Insert the disk into the drive
2. Click the Software tab or software icon.
NOTE: If the DVD setup program does not start automatically, run Launch.exe
from the DVD ROM directory using Windows “My Computer.”
MVC 121 Plus • Software Control 40
