MLA VC10 Plus • Setup Guide (Continued)
2
Application Diagram
RS-232
RELA
Y
V-DC
R
Tx
Rx
G
G
G
V
C
NO
NC
C
PO
WE
R
0.3A MA
X
12V
CONTR
OL
OUTPUT
REMO
TE
CONFIG
DISPL
AY
VOLUME
1
2
3
4
ON
OF
F
MLC 104
IP PLUS
VCR
DVD
PC
XP
A 100
2
1
2
LIMITER/PROTECT
SIGNAL
OVE
R
TEMP
Extron
MLC 104 IP Plus
MediaLink
Controller
Extron
MLA VC10 Plus
Volume Control Module
RS-232
Variable
Impedance
Output
Extron
XPA 1002
Power
Amplifier
Extron
SI 26
Surface-mount
Speakers
Installation
Decide where the unit will be installed. Read the “Mounting” section of the MLA VC10 Plus
User Guide for mounting options.
NOTES:
•
The majority of amplifiers researched and tested by Extron work with
the MLA VC10 Plus default settings as the unit is shipped, with no further
configuration needed.
•
To avoid picking up background noise in the cable, use shielded cable, such
) and place the MLA VC10 Plus
as close as possible to the amplifier. The recommended cable length between
the MLA VC10 Plus and the amplifier should be six feet or less.
