Rack Mounting Procedure
These units can be mounted with optional rack systems listed on the website (see
www.extron.com ).
To mount the unit on a rack shelf, follow the instructions provided with the shelf accessories.
Back of the Rack Mounting Procedure
The MTP can be mounted to the rear of a rack using an optional back of rack mounting kit
(see
www.extron.com ). The kit allows the product to be vertically mounted to the front or
rear rack supports and facing either towards the front or the rear of the rack.
To mount the unit, follow the instructions provided with the kit.
Projector Mounting
Mount the unit onto a projector using an optional Extron pole mount kit. To mount the unit,
follow the instructions provided with the pole mount kit.
MTP 15HD RS Series • Mounting 18
