Pre-Peak switch — The Pre-Peak switch alters the twisted pair signal output to
correct for long cable runs (see
the
on
for suggested switch settings based
on the transmitted video format and transmission distance).
NOTES:
•
The length of the exposed wires in the stripping process is critical. The ideal
length is 3/16 inches (5 mm). If the exposed section is longer, the exposed wires
may touch, causing a short circuit between them. If it is shorter, the wires can be
easily pulled out, even if tightly fastened by the captive screws.
•
Do not tin the wires. Tinned wire does not hold its shape and can become loose
over time.
F
Output connector — Connect one end of a twisted pair cable to this RJ-45 female
connector on the transmitter. Connect the opposite end of the same twisted pair cable
to the RJ-45 female connector on the receiver (see
Twisted Pair Cable Termination
on page 14 to wire the RJ-45 connectors).
ATTENTION: Do not connect these devices to a computer data or
telecommunications network.
