Installation
and Operation
This section provides information on:
• Installation and Operation Overview
• Front Panel Features
• Transmitter Rear Panel Features
• Receiver Rear Panel Features
• Power Supply Wiring and Grounding
• Twisted Pair Cable Termination
• Skew Delay Compensation
• EDID Configuration
Installation and Operation Overview
Follow the steps below to properly install and operate any of the Extron MTP 15HD RS
transmitters and receivers.
ATTENTION: Installation and service must be performed by authorized personnel.
Installation
1. Power off all MTPs and devices. Make sure that the input sources, the MTP, and
the output sources are all powered off and all power sources and signal cables are
disconnected.
2. Connect the transmitter inputs (see Transmitter Rear Panel Features on page 9).
3. Connect twisted pair (TP) cables between the MTP units (see Transmitter Rear Panel
Features on page 9 and Receiver Rear Panel Features on page 11).
4. Connect the receiver outputs (see Receiver Rear Panel Features on page 11).
5. Configure the receiver DIP switches (see Front Panel Features on page 6).
6. Configure the EDID (see Front Panel Features on page 6 and EDID Configuration
on page 16).
7. Connect the power supply and turn on all devices (see Power Supply Wiring and
Grounding on page 12).
8. Adjust the level and peaking (see Front Panel Features on page 6).
9. Adjust the skew delay control (see Front Panel Features on page 6).
10. If applicable, mount the MTPs (see Mounting on page 17).
MTP 15HD RS Series • Installation and Operation 5
