IN1776QZX OPERATION MANUAL - REV 1.4 11/27/99

IN1776QZX

Scan Converter

Input

Connector Type

15-pin HD Male (Adapter provided for MAC)

Compatible Formats

RGB / RGBS / RGsB / RGBHVS

Compatible Resolutions

VGA: 640 x 480, 800 x 600, 1024 x 768
MAC: 512 x 384, 640 x 480, 832 x 624, 1024 x 768

Horizontal Scan Rate

24 KHz to 66 KHz

Vertical Refresh Rate

50 Hz to 100 Hz

Output

Local Monitor

15-pin HD Female (Adapter provided for MAC)

Composite Video

(1) RCA Female & (1) BNC Female

S-Video

(1) 4-pin Female Mini-DIN for Y/C

RGB Video

(4) BNC Female for RGBS

Power

Power Supply

Internal 115 / 230 VAC, 50 / 60 Hz (selectable)

Fuse

110VAC: 250mA / 250V, Time Delay
220VAC: 125mA / 250V, Time Delay

Power Consumption

15 Watts

Dimensions

Size

1.75” x 11.75” x 6.5” / 4.5cm. x 29.8cm x 16.5cm

Product Weight

4 lbs. / 1.8 kg.

Shipping Weight

7 lbs. / 3.5 kg.

Regulatory Approvals

UL1950, CAN/CSA-22.2 No. 950, Third Edition
CE: EN55022 (1987), EN50081-1 (1991)
EN50082-1 (1992 and 1994), EN60950-92

INCLUDED ACCESSORIES

IN1776QZXIR Infrared Remote Control, (4) AAA batteries
IN9095 Composite Video Cable, RCA Male to RCA Male, 6’
IN8606 S-Video Cable, 4-Pin Mini DIN Male to Male, 6’
IN8006 VGA Input Cable, 15-Pin HD Male to Female, 6’
IN9097 MAC Input Cable, 15-Pin D Male to 15-Pin HD Female, 6’
IN9099 MAC Output Cable, 15-Pin D Female to 15-Pin HD Male, 1’

A/C Power Cord

OPTIONAL ACCESSORIES

IN9121 Rack Mount Ears, mounts IN1776QZX in 1U rack space
IN9046 BNC Input Cable, 15-Pin HD Female to (5) Male BNC, 12’
IN7000-4 Series RGBS Output Cables - Available in a variety of

lengths from 6’ to 250’
