ADAPTER / EXTENSION CABLES FOR INPUT AND LOCAL MONITOR OUTPUT

The IN2116 has 15-pin HD VGA-type connectors for input and local monitor output. The following input
and local monitor output cables are available:

Computer

3’

6’

12’

25’

VGA: 15-Pin HD

Input Cable

IN8006

IN8012

IN8025

Output Cable (Optional)

IN8006

IN8012

IN8025

MAC with 15-Pin D:

Input Cable

IN9140

IN9144

Output Cable

IN9141

IN9145

MAC G3, G4 and PowerBook with 15-Pin HD*:

Input Cable

IN8006

IN8012

IN8025

Output Cable

IN8006

IN8012

IN8025

SUN: 13W3

(

may also be used with SGI with RGsB output)

Input Cable

IN9142

IN9146

Output Cable

IN9143

IN9147

Workstation: 5 BNC

Input Cable

IN9048

IN9046

IN9046-L25

Output Cable

IN9047

IN9045

IN9046-L25

Workstation: 4 BNC

Input Cable

IN9100

*Newer Mac G3 models (with translucent cases) have 15-Pin HD connectors (pins arranged in 3 rows).
Older G3 models (with solid white enclosures) incorporate 15-Pin D connectors (pins arranged in 2 rows).

Note: The input / output cables listed above can be used with any of the following interfaces, distribution
amplifiers and switchers:

IN2100

IN2200

IN2110

IN3260

IN2111 Series

IN3262 Series

IN2112 Series

IN3264

IN2114 Series

IN3268

IN2116

IN3600 Series
