ISM 1WB and 2WB Output Board • Setup Guide, cont’d
2
Command ASCII comm
(host to ISM )
Response
(ISM to host)
Additional description
Input selection
Video and audio X! *X@! OutX@•InX!•All] Tie video/audio input X! to X@.
Video X! *X@& OutX@•InX!•RGB] Tie video input X! to output X@.
Audio X! *X@$ OutX@•InX!•Aud] Tie audio input X! to output X@.
Volume control
Set volume X@ *X3$V OutX@•VolX3$] Set volume to X3$ for output X@.
Increment X@ +V OutX@•VolX3$] Increase volume.
Decrement X@ -V OutX@•VolX3$] Decrease volume.
View X@ V X3$] View current volume setting.
Audio gain and attenuation
Specific gain X! *X3@G InX!•AudX3!] Set input X! gain to X3!.
Set attenuation X! *X3#g InX!•AudX3!] Set input X! attenuation to X3#.
Increment X! +G/g InX!•AudX3!] Raise input X! audio level to X3!.
Decrement X! -G/g InX!•AudX3!] Lower input X! audio level to X3!.
View X! G/g X3!] View audio level of input X!.
RGB Delay
Delay on 3*X@*X3&# X@DlyX3&] Set RGB delay.
View setting 3*X@# X3&] View RGB delay setting.
Video mute
Mute on X@ *1B X@Vmt1] Mute selected video output.
Mute off X@ *0B X@Vmt0] Unmute selected video output.
View X@ B X1)] View the mute status.
Audio mute
Mute on X@ *1Z X@Amt1] Mute selected audio output.
Mute off X@ *0Z X@Amt0] Unmute selected audio output.
View X@ Z X1)] View mute status.
Board-specific SIS commands
Specific SIS commands can be used with the ISM 1WB and ISM 2WB boards.
Refer to the ISM 824 User Guide at
www.extron.com, for a detailed command list.
NOTE:
X! = Input number, 0-8
X@ = Output number, 1-8
X1) = Mode status, 1 = on, 0 = off
X3! = Audio level adjustment range (-18 to +24)
X3@ = Audio gain adjustment range (0 to 24)
X3#
= Audio attenuation adjustment range (18 to 0)
X3$ = Volume adjustment range (0 - 64)
X3& = RGB delay duration 00 to 50 in 0.1 second increments (0.0 second to 5.0 seconds)
