HRP 100 • Installation Guide

The Extron

®

HRP 100 is a one unit high, blank panel that fits in a half-rack width

installation.
Extron does not provide rails for the rack system. These must be purchased and
installed separately (see the user guide provided by the supplier). The distance between
the rails must be half the standard rack width
(8.85 inches or 22.48 cm) between the inside
edges of the rails (see the figure to the right).
Follow these instructions to install the half-
rack panel.

1.

Position the rack panel to cover a gap in
the equipment rack. Align the holes in
the panel with the holes in the rack.

2.

Secure the panel to the equipment rack
using the four provided #10-32 screws
with captive washers.

Extron

HRP 100

1U Blank panel

8.85"
