Resetting the component code
If, for any reason, the component device code is erased, reset the code with
the following instructions:
1.
Press and release the S (set) button.
2.
Press and release the SWP SWITCHER button.
3.
Enter the component’s three digit code number using the numeric
buttons: 001.
4.
Press and release the ENT (ENTER) button to store the code.
Other CTL120-3 functions
The following button functions are also included for the SWP123.*
•
MIC — + (increase) and – (decrease) microphone volume adjustment
•
VOL — + (increase) and – (decrease) Master Audio ouput adjustment
•
Talk Over — activate the microphone mixer for microphone talk over
•
Mute — mute/unmute Master Audio output
•
Blank — suppress the video/audio input to the selected A/V group
* The remaining buttons do not apply to the SWP123 operation.
