CC200 Series Control and Audio Link Cables
68-921-01
Rev. A
02 04
Printed in the USA
The Extron CC200 Series cable assemblies are designed specifically for use with Pioneer
and Sharp plasma and LCD displays that operate with external switcher/scaler boxes
(see list, opposite side). The assemblies feature DFP male connectors and a proprietary
cable design and pinout configuration.
Pin
Function
1
RXDO_M
2
GROUND
3
SENCE
4
NC
5
SMPOW
6
GROUND
7
CCKM
8
CSEN2
9
CSEN1
10
NC
Pin
Function
11
TXDO_M
12
GROUND
13
SP_R
14
SR_DOWN
15
SR_UP
16
GROUND
17
FLASH_W
18
SRST
19
GROUND
20
SP_L
1
10
11
20
Male
CC200 Series Control and Audio Link Cables (continued)
Compatible display systems (partial list)
Pioneer PDP-4330HD
43" plasma display with Media Receiver
Pioneer PDP-5030HD
50" plasma display with Media Receiver
Sharp LC-30HV2U
30" LCD display with AVC System
Sharp PZ-43HV2U
43" plasma display with AVC System
Sharp PZ-50HV2U
50" plasma display with AVC System
Part numbers
CC200-L25 ..................................... 25' (7.6 m) .................... 26-583-01
CC200-L35 ..................................... 35' (10.7 m) .................. 26-583-02
CC200-L50 ..................................... 50' (15.2 m) .................. 26-583-03
CC200-L60 ..................................... 60' (18.3 m) .................. 26-583-04
CC200-L75 ..................................... 75' (22.9 m) .................. 26-583-05
