Page 2
BNC Termination Kit Instructions
______ This document is a compilation of Extron’s instructions, together with
copies of AMP® Instruction booklets that are provided with each of the
AMP tools included in this kit.
1 • Extron Mini-High-Res Cable-to-BNC Instructions
Parts included in Kit • Pre-cut Heat shrink insulation:
Red 3/8” diameter
Green 3/8” diameter
Blue 3/8” diameter
Yellow 3/8” diameter
Black 3/8” diameter
3 • AMP® Coaxial Cable Stripper Instructions (4100-0632)
5 • AMP® 75-Ohm BNC Plug Instructions (408-9088)
Parts included in Kit • BNC connectors for cable ends:
Male plug bodies
Center contacts
Tube for insulation
Step-down Ferrule
7 • AMP® Pro-Crimper II Hand Tool & Die Assembly Instructions (408-4218)
8 • AMP® Pro-Crimper II Hand Tool Application & Maintenance (408-9930)
10 • AMP® Series BNC Solder Receptacle Jacks (IS 2858)
89-04
68-197-02
Rev. B
Written & printed in USA
