Commands and Functions

Returns a specified parameter from a connected SDI-12 sensor. The X following the

identifier specifies the SDI-12 sensor’s address. The N or NN denotes the parameter to

return. For example, to request the 3rd parameter from an SDI-12 sensor on address 0, the

identifier SDI03 would be used.

SDI-12 requests and responses are cached to allow quick retrieval of subsequent parameter

requests. To force a new measurement to be made for a sensor, the CLEARSDI( ) function

should be used to clear the SDI-12 cache. Prior to making SDI-12 requests in a Basic

program, the CLEARSDI( ) function should probably be called to force new measurements.

CLEARSDI()

GETVALUE SDI01, sdi1$

REM sets sdi1$ to parameter 1 from sensor 0

GETVALUE SDI312, sdi2$

REM sets sdi12$ to parameter 12 from sensor 3

SDIXN or SDIXNN

Returns a sensor’s most recent processed value. If an unknown sensor is specified, the Error

String (default is -99.99) is returned. Prior processed values can be returned by adding an

additional numerical parameter. The number 1 indicates the most recent measurement, 2

the previous measurement, 3 the value processed three scans prior, etc. Values from SDI-

12 or Basic programs are retrieved by specifying the name of the sensor followed by the

parameter’s name surrounded by parentheses.

GETVALUE SENSOR “H-377”, temp$

GETVALUE SENSOR “H-340SDI(Rainfall)”, stage$

GETVALUE SENSOR “H-340SDI(Rainfall)” 2, previous_stage$

SENSOR

Returns a new counter measurement from the specified Digital port.TheXfollowing the

identifier specifies which digital portis measured.See SetValue to change the counter value

of a specific digital port

GETVALUE COUNTER1, c1$ REM sets c1$ to the Digital port’s count

GETVALUE COUNTER2, c2$ REM sets c1$ to the Digital port’s count

COUNTERX

Returns a new measurement from the specified Digital port.A 1 or 0 will be returned based

on the port’s level, 1 indicating the port is high (>3.5V), 0 indicating the port is low (<0.08V).

TheXfollowing the identifier specifies which digital portis measured. See SetValue to change

the level measurement of a specific digital port.

GETVALUE DIGITAL1, d1$ REM sets d1$ to 1 or 0, based on port level

GETVALUE DIGITAL2, d2$ REM sets d2$ to 1 or 0, based on port level

DIGITALX
