2

SAFETY

INSTRUCTIONS

This safety alert symbol will be used in this manual and on the

pump safety instruction decals to draw attention to safety re-

lated instructions. When used the safety alert symbol means

ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

FAILURE TO FOLLOW THE INSTRUCTIONS MAY RESULT IN A

SAFETY HAZARD.
Your pump should have the following safety instruction decals

located approximately as shown. If the decals are missing or are

illegible contact your local representative for a replacement.

Additional Safety Requirements:
1. Electrical connections to be made by qualified Electrician in

accordance with all National, State and Local codes.

2. Motor must have properly sized starter with properly sized

heaters to provide overload and undervoltage protection.

3. If pump, motor or piping are operating at extremely high or

low temperatures, guarding or insulation is required.

4. The maximum working pressure of the pump is listed on the

pump nameplate, do not exceed this pressure.

DESCRIPTION

This centrifugal pump is a close coupled pump which

features – high efficiency, rugged construction, foot mounted

motor. These features make installation, operation and service

easy to perform.

PUMP APPLICATION

This centrifugal pump’s bronze fitted construction make it ideal

with service with the following liquids: fresh water, general

pumping and benign liquids.
