Installation

Preinstallation

Precautions

WARNING:

• When installing in a potentially explosive environment, make sure that the motor is

properly certified.

• You must earth (ground) all electrical equipment. This applies to the pump

equipment, the driver, and any monitoring equipment. Test the earth (ground) lead to
verify that it is connected correctly.

NOTICE:
Supervision by an authorized Xylem representative is recommended to ensure proper
installation. Failure to do so may result in equipment damage or decreased performance.

Pump location guidelines

WARNING:
Assembled units and their components are heavy. Failure to properly lift and support this
equipment can result in serious physical injury and/or equipment damage. Lift equipment
only at the specifically identified lifting points. Lifting devices such as eyebolts, slings, and
spreaders must be rated, selected, and used for the entire load being lifted.

Guideline

Explanation/comment

Keep the pump as close to the liquid source as

practically possible.

This minimizes the friction loss and keeps the suction piping

as short as possible.

Make sure that the space around the pump is

sufficient.

This facilitates ventilation, inspection, maintenance, and

service.

If you require lifting equipment such as a hoist or

tackle, make sure that there is enough space above

the pump.

This makes it easier to properly use the lifting equipment and

safely remove and relocate the components to a safe location.

Protect the unit from weather and water damage due

to rain, flooding, and freezing temperatures.

This is applicable if nothing else is specified.

Do not install and operate the equipment in closed

systems unless the system is constructed with

properly-sized safety devices and control devices.

Acceptable devices:

• Pressure relief valves
• Expansion tanks
• Pressure controls
• Temperature controls
• Flow controls

If the system does not include these devices, consult the

engineer or architect in charge before you operate the pump.

Take into consideration the occurrence of unwanted

noise and vibration.

Vibration can be transmitted to the piping system, which can

result in objectionable noise away from the pump.

If the pump location is overhead, undertake special

precautions to reduce possible noise transmission.

Consider a consultation with a noise specialist.

When possible, locate the pump below the fluid

level.

This facilitates priming, ensures a steady flow of liquid, and

provides a positive suction head on the pump.
