24 EN 6.81 Modbus Communication Module 205546 Manual 1212
Status I/O Bits
Register
address
Register name Type Security Read/Write
1004
Status no. 1 B16 None Read-only
Bits
Oxix
Bit 1 = converter has experienced a software or hardware reset
(expected if sensor number has been changed or factory setting is reloaded)
Bit 2 = system error alarm (see settings for possible enable / disable and on delay)
Bit 3 = sensor error alarm (see settings for possible enable / disable and on delay)
Bit 4 = sensor autodetect type is running - normal if sensor com error is detected x times
Bit 5 = hold of measurment value (normal for a short time)
Bit 6 = sensor cleaning in progress
Bit 7 = limit control
SuSix
Status bit { on = 1 & off = 0 }
Bit 1 = converter has experience a software or hardware reset
(expected if sensor number has been changed or factory setting is reloaded)
Bit 2 = system error alarm (see settings for possible enable / disable and on delay)
Bit 3 = sensor error alarm (see settings for possible enable / disable and on delay)
Bit 4 = sensor autodetect type is running - normal if sensor com error is detected x times
Bit 5 = hold of measurment value (normal for a short time)
Bit 6 = sensor cleaning in progress
Bit 7 = limit control
Login
Reg.
addr.
Reg.
name
Type
Se-
cu-
rity
Read/
Write
Oxix SuSix
5000
Login -
Value
U16 None Read/
Write
Write = 0 or 65535 to
logout
Write = 0 or 65535 to logout
5001
Min. U16 None Read-
only
0
0
5002
Max. U16 None Read-
only
65.535
65.535
5003
Login
status
- value
U16 None Read/
Write
Login status
Read = { 65535 = lockout
mode - 0 = no code -
1 = code accepted }
Login status
Read = { 65535 = lockout
mode - 0 = no code -
1 = code accepted }
5004
Not in
use
U16 None None
5005
Not in
use
U16 None None
Table 3. Oxix and SuSix Register List
