16 EN 6.81 Modbus Communication Module 205546 Manual 1212
4. Register Lists
4.1 MagFlux Register List
• Date: 2009-03-10
• Firmware: 842009-001
• Protocol: Modbus RTU
• Transfer rate: 9600 baud
• Format for serial com: 1-Startbit, 8-Databits, 1-Parity (Even), 1-Stopbit
• Password: OFF (default)
• To set up the converter, use the MagFlux Display Unit
When a MagFlux Converter is connected to an external master, for example a
PLC or an HMI interface, the MagFlux Display Unit can not be used simulta-
neous on the RS 485 communication port.
Support only Read is ”func. 03 (0x03) Read Holding Registers” or ”func. 04
(0x04) Read Input Registers” and write ”func. 16 (0x10) Write Multiple regis-
ters”
Register
address
Register
name
Type Security
Read/
Write
Comments
Flow now
600
Flow now F32 {low} None Read-only Flow now [m3/sec]
601
Flow now F32
{high}
- -
Flow now [m3/sec]
Totalizer Forward
604
Total forward flow 1 -
LS word
U64{1} None Read-only
Forward total [mm3]
605 Total forward flow 1 - 2 U64{2} - Read-only Forward total [mm3]
606 Total forward flow 1 - 3 U64{3} - Read-only Forward total [mm3]
607
Total forward flow 1 -
MS word
U64{4} - Read-only
Forward total [mm3]
608
Resetable total forward
flow 2 - value
U32 {low} Password Read/
Reset
Forward total [liter]
609
Resetable total forward
flow 2 - value
U32
{high}
- Read/
Reset
Forward total [liter]
Totalizer Reverse
610
Total reverse flow 1 -
LS word
U64{1} None Read-only
Reverse total [mm3]
611 Total reverse flow 1 - 2 U64{2} - Read-only Reverse total [mm3]
