17
Register
address
Register
name
Type Security
Read/
Write
Comments
612 Total reverse flow 1 - 3 U64{3} - Read-only Reverse total [mm3]
613
Total reverse flow1 -
MS word
U64{4} - Read-only
Reverse total [mm3]
614
Resetable total reverse
flow 2 - value
U32 {low} Password Read/
Reset
Reverse total [liter]
615
Resetable total reverse
flow 2 - value
U32
{high}
- Read/
Reset
Reverse total [liter]
Totalizer Sum
616
Total sum flow 1 -
LS word
S64{1} None Read-only
Sum total [mm3]
Sum total= (Forward +
Reverse)
{exsample. 12 + (-2)
=10 mm3}
617 Total sum flow 1 - 2 S64{2} - Read-only See above
618 Total sum flow 1 - 3 S64{3} - Read-only See above
619
Total sum flow 1 - MS
word
S64{4} - Read-only
See above
620
Resetable total sum flow 2
- value
S32 {low} Password Read/
Reset
Sum total [liter]
621
Resetable total sum flow 2
- value
S32
{high}
- Read/
Reset
Sum total [liter]
Batch Counter 1
627
Batch counter 1 -
Batch count
U32 {low} Pass-
word*
R/Reset
(* = password can
be disabled for this
setting )
628
See above U32
{high}
- -
629
Batch counter 1 - value
batch now
F32 {low} None Read-only
630
See above F32
{high}
- -
631
Batch counter 1 - value
batch missing
F32 {low} None Read-only
632
See above F32
{high}
- -
Batch Counter 2
633
Batch counter 2 - batch
count
U32 {low} Pass-
word*
R/Reset
(* = password can
be disabled for this
setting )
634
See above U32
{high}
- -
635
Batch counter 2 - value
batch now
F32 {low} None Read-only
636
See above F32
{high}
- -
4. Register Lists
Modbus Communication Modules
