19
Register
address
Register name Type Security
Read/Write
1004
Status bits (Part 2) B16 None Read-only
Bits
Bit 1 = flow direction bit - forward flow = 0 / reverse flow = 1 (see settings for possible delay)
Bit 2 = flow direction bit - A = 0 / B = 1 (see settings for possible delay)
Bits 3-16 = reserved and read-value is 0 (zero)
Login
5000
Login - value U16 None Read/
Write
Write = 0 or 65535 to logout
5001
Min. U16 None Read-
only
0
5002
Max. U16 None Read-
only
65.535
5003
Login status -
value
U16 None Read/
Write
Login status
read = { 65535 = lockout mode - 0 = no
code - 1 = code accepted }
5004 Not in use U16 None None
5005 Not in use U16 None None
Batch Counter 1
6703
Stop / Start /
Pause Manual
Batch - value
U16 None R/W
Stop / start / pause start manual batch
0 = stop
1 = start
2 = pause
6704
Min. U16 None Read-
only
0
6705
Max. U16 None Read-
only
2
6706
Batch stop
volume - value
F32
{low}
Pass-
word*
Read/
Write
[m 3 ] (* = password can be disabled for
this setting )
6707
See above F32
{high}
- -
6708
Min. F32
{low}
None Read-
only
6709
See above F32
{high}
- -
6710
Max. F32
{low}
None Read-
only
6711
See above F32
{high}
- -
Batch Counter 2
6753
Stop / Start /
Pause Manual
Batch - value
U16 None Read/
Write
Stop / start / pause start manual batch
0 = stop
1 = start
2 = pause “
6754
Min. U16 None Read-
only
0
4. Register Lists
Modbus Communication Modules
