Xylem A-100NV DIGITAL PERISTALTIC PUMPS - Manual (Page 7)

Page 7
CIRCUIT BOARD CONNECTIONS
AC sine waves
Jumper Not Installed
(open - factory default)
Digital square waves
Jumper Installed
DC
MOTOR
BLACK (-)
RED (+)
Ground (green) Earth Ground (green)
Common
Hot
AC
Input
Power
PROTECTOR FUSE
1 Amp, 250 Volt AC
(Littlefuse #239001
or Equivalent)
1 AMP
250VAC
MOTOR
RED (+)
MOTOR
BLACK (-)
AC LINE
NEUTRAL
AC LINE
HOT
TS
THERMAL SWITCH
.187 push tab connectors
2 conductors
11
0
11
0
202
AC LINE VOLTAGE SETTINGS
230 VAC
One Jumper Installed
on center position
(ends open)
115 VAC
Two Jumpers Installed
on end positions
(no open pins)
BLUE (4-20 mA input)
BLACK (Ground)
YELLOW (verification sensor input)
ORANGE (0-10 VDC input)
RED (+20VDC)
WHITE (frequency input)
JUNCTION BOX
LIQUID-TIGHT
CONNECTOR
ACCEPTABLE CABLE JACKET RANGE:
.118 - .255 INCH
.(
3,0 - 6,5 MM)
EXTERNAL INPUT CABLE
BROWN (motor-on contact output)
INPUT SIGNAL CONNECTOR
7 wire bundle
Hz INPUT JUMPER SETTINGS
Located under connector
PR
BEO CN
ON
ALARM OUTPUT
(CONTACT CLOSURE)
normally open (NO)
(factory default)
TUBE FAILURE SENSOR
PROBE INPUT
2 Grey wires pump head sensors.
PURPLE X2 (alarm relay contacts)
A-100NV
