Chapter 2 installation, H-3551 – Xylem H-3551 User Manual
Page 7
Chapter 2
Installation
H-3551
Installation 2-1
2.1 Installing the W
ATER
LOG
®
Series Model H-3551
For proper installation of the H-3551, you will need:
! The H-3551
! This Owner's Manual
! RS-485 serial cable (provided)
! Installation kit (provided)
Installation instructions for the H-3551 may vary somewhat according to your specific application and field
conditions.
The photo below shows the input/output panel of the H-3551 where you make connections for power,
ground, communications, outlet to orifice, and pressure to your sensor. Observe the labels to determine
where you should make your connections.
