6
Customer/Technical Service
Pneumatic Division
Richland, MI 49083 Tel: (269) 629-2550
Fax: (269) 629-2475
WILKERSON WARRANTY
Wilkerson products are warranted to be free from defects in material
and workmanship, under proper use, installation, application and
maintenance in accordance with Wilkerson's written recommendations
and specification for a period of one year from the date of shipment from
the factory (refrigerated dryers are warranted for 2 years). Wilkerson's
obligation under this warranty is limited to, and the sole remedy for any
such defect shall be, the repair or replacement (at Wilkerson's option)
of unaltered products returned to Wilkerson and proven to have such
defect, provided such defect is promptly reported to Wilkerson within
said one-year period.
This is the only authorized Wilkerson Warranty and is in lieu of all
other express or implied warranties or representations, including
any implied warranties of merchantability or fitness, or of any
other obligations on the part of Wilkerson.
Warranty claims must be submitted and shall be processed in
accordance with Wilkerson's established warranty claim procedure.
In no event will Wilkerson be liable for business interruptions, loss of
profits, personal injury, costs of delay or for any other special, indirect,
incidental or consequential losses, cost or damages.
WARNING: USE LIMITATIONS
Wilkerson's warranties are void, and Wilkerson assumes no
responsibility for any resulting cost, loss, injury or any other damages
whatsoever, with respect to any plastic bowl unit for which a bowl
guard is standard equipment if the unit is placed in service without the
bowl guard and, except as otherwise specified in writing by Wilkerson,
with respect to any Wilkerson products which are used in other than
compressed air service. Specific warnings with respect to these and
other use limitations appear elsewhere in this catalog.
Wilkerson maintains a policy of ongoing product development
and improvement. We therefore reserve the right to change
dimensions specification and design without notice.
DO NOT PLACE PLASTIC BOWL UNIT IN SERVICE
WITHOUT BOWL GUARD INSTALLED
Plastic bowl units are sold only with bowl guards with the exception
to miniature units (C04, F00, L00, and M00). To minimize the danger
of flying fragments in the event of plastic bowl failure, the bowl guards
should not be removed. If the unit is in service without the bowl guard
installed, manufacturer's warranties are void, and the manufacturer
assumes no responsibility for any resulting loss.
If the unit has been in service and does not have a bowl guard,
order one and install before placing back in service.
CAUTION
Certain compressor oils, chemicals, household cleaners, solvents,
paints and fumes will attack plastic bowls and can cause bowl failure.
Do not use near these materials. When bowl becomes dirty replace
bowl or wipe only with a clean, dry cloth. Reinstall bowl guard or buy
and install a bowl guard. Immediately replace any crazed, cracked,
damaged or deteriorated plastic bowl with a bowl or a new plastic bowl
and bowl guard.
CAUTION
Except as otherwise specified by the manufacturer, this product is
specifically designed for compressed air service, and use with any
other fluid (liquid or gas) is a misapplication. For example, use with or
injection of certain hazardous liquids or gases in the system (such as
alcohol or liquid petroleum gas) could be harmful to the unit or result
in a combustible condition or hazardous external leakage. Before using
with fluids other than air, or for non-industrial applications, or for life
support systems, consult Wilkerson Corporation for written approval.
SOME OF THE MATERIALS THAT WILL ATTACK
POLYCARBONATE PLASTIC BOWLS.
Acetaldehyde Chlorobenzene Methylene chloride
Acetic acid (conc.) Chloroform Methylene salicylate
Acetone Cresol Milk of lime (CaOH)
Acrylonitrile Cyclohexanol Nitric acid (conc.)
Ammonia Cyclohexanone Nitrobenzene
Ammonium fluoride Cyclohexene Nitrocellulose lacquer
Ammonium hydroxide Dimethyl formamide Phenol
Ammonium sulfide Diozane Phosphorous hydroxy
Anaerobic adhesives Ethgane tetrachloride chloride
and sealants Ethyl acetate Phosphorous trichloride
Antifreeze Ethyl ether Propionic acid
Benzene Ethylamine Pyridine
Benzoic acid Ethylene chlorohydrin Sodium hydroxide
Benzyl alcohol Ethylene dichloride Sodium sulfide
Brake fluids Ethylene glycol Styrene
Bromobenzene Formic acid (conc.) Sulfuric acid (conc.)
Butyric acid Freon (refrig. & Propell.) Sulphural chloride
Carbolic acid Gasoline (high aromatic) Tetrahydronaphthalene
Carbon disulfide Hydrazine Tiophene
Carbon tetrachloride Hydrochloric acid (conc.) Toluene
Caustic potash solution Lacquer thinner Turpentine
Caustic soda solution Methyl alcohol Xylene
Perchlorethylene
& Others
TRADE NAMES OF SOME COMPRESSOR OILS, RUBBER
COMPOUNDS AND OTHER MATERIALS THAT WILL ATTACK
POLYCARBONATE PLASTIC BOWLS.
Atlas “Perma-Guard” National Compound #N11
Buna N “Nylock” VC-3
Cellulube #150 and #220 Parco #1306 Neoprene
Crylex #5 cement *Permabond 910
*Eastman 910 Petron PD287
Garlock #98403 (polyurethane) Prestone
Haskel #568-023 Pydraul AC
Hilgard Co.'s hil phene Sears Regular Motor Oil
Houghton & Co. oil #1120, Sinclair oil “Lily White”
#1130 & #1055 Stauffer Chemical FYRQUEL #150
Houtosafe 1000 Stillman #SR 269-75 (polyurethane)
Kano Kroil Stillman #SR 513-70 (neoprene)
Keystone penetrating oil #2 Tannergas
*Loctite 271 Telar
*Loctite 290 Tenneco anderol #495 & #500 oils
*Loctite 601 Titon
*Loctite Teflon-Sealant *Vibra-tite
Marvel Mystery Oil Zerex
Minn. Rubber 366Y
*When in raw liquid form.
We cannot possibly list all harmful substances, so check with
Mobay or the General Electric office for further information on
polycarbonate plastic.
The trade names “EconOmist” and “Flow-Guide”
are registered at the United States Patent Office.
“Auto-Fill”, “Dial-Air”, “Flex-Drain”, “Mainliner” and
“Whirl-Flo” are trade names of the Wilkerson Corporation.
WILKERSON PRODUCTS ARE PROTECTED BY THE
FOLLOWING U.S. PATENT AND PATENTS IN OTHER
COUNTRIES, ADDITIONAL PATENTS ARE PENDING.
3,631,878 3,667,493 3,762,224 4,215,790
4,215,790 3,793,803 4,718,245 3,793,803
3,858,403 D-292-310 D-229-629 4,215,790
4,289,335 4,352,511 4,559,065 4,631,073
4,689,969 4,696,320 3,889,484 3,945,465
4,631.073 D-234-848
