H-3521
Simple RS-232 Menu Interface 4-3
4.3 Menu Options
4.3.1 P - Sensor Mode Options
In this sub-menu you can view the current H-3521 power mode settings or other modes if
available and change the modes if desired. Refer to section 4.4 for the Sensor Mode
Options sub-menu options.
4.3.2 V - Sensor Output Options
In this sub-menu you can view the current H-3521 output options and enables. In this sub-
menu you can change these options and enables. Refer to section 4.5 for the Sensor
Output Options menu options.
4.3.3 A - SDI-12 Address
This option is for editing the SDI-12 sensor address of the H-3521. The following prompt
appears the bottom of the menu.
Enter Option >Enter New SDI-12 Address [ ]
Enter the desired SDI-12 sensor address (0-9, a-z, A-Z), the menu will refresh with the
new address.
4.3.4 S - Stage
This option is for displaying the last measured stage value and also for setting the current
stage. The following prompt at the bottom of the menu.
Enter Option >Enter Stage Value[ ]
Enter the stage setting you desire and press the ENTER key. The message
“Calculating New Offset...” will then be displayed. The H-3521 makes a new
measurement and then calculates the offset needed to obtain the desired stage setting.
When the measurement is complete the offset value will have changed. You must make a
new measurement “M” to see the results of the new offset.
4.3.5 D - Digits
This option is for displaying the current stage digits to the right of the decimal and also
for editing the number of digits to the right of the decimal. After pressing the D key the
user will see the following prompt at the bottom of the menu.
Enter Option >Stage Digits [ ]
4.3.6 O - Offset
This option is for displaying the current stage offset value and also for editing the stage
offset value manually. The following prompt appears at the bottom of the menu.
Enter Option >Enter Offset Value[ ]
Enter the desired stage offset value and press the ENTER key to input the value. The
