Chapter 4
Simple Menu Interface
H-3521
Simple RS-232 Menu Interface 4-1
4.0 Simple Menu Interface
The H-3521 has a RS-232 interface which is convenient for setup and testing. This chapter is a
description of the Simple Menu interface. Included is a description of the menu and each setup
option.
4.1 Connecting to the H-3521
The Simple Menu interface is designed to work with a terminal program such as Hyper-
Terminal, Procom or other similar terminal programs. The following table shows the settings that
are needed for communication with the H-3521.
COMMUNICATION
SETTING H-3521 SETTINGS
BAUD RATE:
DATA BITS:
STOP BITS:
PARITY:
DUPLEX:
TERMINAL EMULATION:
FLOW CONTROL: 9600
8
1
None
Full
VT-100
Software (Xon / Xoff)
After the computer is connected, pressing any key ONCE! (while the H-3521 is in sleep mode)
will cause the H-3521 to wake up, make a new measurement and print the following message:
Stage = +/-X.XX
Temp = +/-XX.X
When the ENTER key is pressed after the H-3521 is awake it will invoke the H-3521 Simple
Menu. You will see a “Measuring...” message displayed as the H-3521 makes a fresh
measurement. Then the H-3521 will display the Simple Menu as shown on the following page.
