MIQ/R6 Settings
4 - 15 ba76031e01 01/2012
As soon as a function is selected for a relay output, a relay action can
be selected (see section 4.5.1).
4.5.1 Relay action
The following actions of the relay can be laid down in the Action setting:
Note
Preferably set up the relay output as normally closed for monitoring
functions (Action, Open).
Function Description
No function The relay output is not used.
System monitoring see section 4.5.2
Sensor monitoring see section 4.5.3
Limit indicator see section 4.5.4
Frequency controller see section 4.5.5
Pulse-width output see section 4.5.6
Reinigung see section 4.5.7
Sensor-controlled see section 4.5.8
Manual control see section 4.5.9
Alarm contact see section 4.5.10
8 Carry out the settings for the relay outputs with
d
and
g
.
The settings include the relay action (see section 4.5.1) and
sensor-dependent settings.
9 Highlight and confirm Save and quit with
d
and
g
.
The new settings are stored.
Settings Explanations
Open The relay should open if any event occurs.
Close The relay should close if any event occurs.
