4
SSV PRODUCT LINE NUMBERING SYSTEM
MODEL NOMENCLATURE (Sizes 33SV - 92SV)
The various versions of the SSV line are identifi ed by a product code number on the pump label. This number is also the catalog number for the pump. The
meaning of each digit in the product code number is shown below. Note: Not all combinations are possible. Consult your G&L Pumps distributor.
EXAMPLE PRODUCT CODE ➤
33 SV B G 1 2 R 6 T A H
Pump Options (optional):
H = Horizontal mounting
D = High Pressure Pump (DPS)
Q= 1.0 Service Factor Version (AQ) T = Alternative Motor Frame
Seal Options:
Motor Enclosure:
D = ODP
T = TEFC
X = Explosion Proof P = TEFC Premium Effy
Motor Voltage:
1 = 115/230
3 = 230/460 5 = 575 7 = 200
2 = 230 4 = 460 6 = 208-230/460 8 = 190/380
HP Rating:
G = 2 HP
M = 15 HP S = 50 HP
H = 3 HP N = 20 HP T = 60 HP
J = 5 HP P = 25 HP U = 75 HP
K = 7½ HP Q = 30 HP
L = 10 HP R = 40 HP
Motor Hertz/Speed/Phase:
1 = 60 Hz/3500/1
4 = 60 Hz/1750/3 7 = 50 Hz/1450/1
2 = 60 Hz/3500/3 5 = 50 Hz/2900/1 8 = 50 Hz/1450/3
3 = 60 Hz/1750/1 6 = 50 Hz/2900/3 9 = 60 Hz/Variable/3
Number of Reduced Impellers (can be 0, 1, 2) *
Total Bowls/Stages:
A = 1
E = 5 J = 9
B = 2 F = 6 K = 10
C = 3 G = 7
D = 4 H = 8
Flange Orientation:
B = Cast Iron/316 stainless steel, in-line ANSI fl ange
D = 316 stainless steel, in-line ANSI fl ange
Product Line:
Stainless Vertical Vertical
Nominal Flow:
33 = 150 GPM 66 = 350 GPM
46 = 225 GPM 92 = 450 GPM
* NOTE: Indicates number of reduced diameter impellers in the total staging.
(Two would indicate 2 reduced diameter impellers.)
Code No. Rotary Stationary Elastomers
A
Carbon
Viton
Mechanical Seal
B EPR
C
Silicon Carbide Silicon Carbide
Viton
D EPR
Cartridge Seal
L Carbon Viton
P Silicon Carbide EPR
– Metal parts on all seals are 316SS.
– Silicon carbide is graphite fi lled.
