SSV PRODUCT LINE NUMBERING SYSTEM
The various versions of the SSV line are identifi ed by a product code number on the pump label. This number is also the catalog number for the pump. The
meaning of each digit in the product code number is shown below. Note: Not all combinations are possible. Consult your G&L Pumps distributor.
MODEL NOMENCLATURE
(Sizes 1SV - 4SV)
2 SV A 1 D 2 B 0 H
EXAMPLE
PRODUCT
CODE
H = Horizontal Mount VIC = Victaulic Connection (1SVB/D – 4SVB/D only)
Mechanical Seal Options:
Number of Stages:
B = 2
F = 6
K = 10
P = 14
V = 20
C = 3
G = 7
L = 11
Q = 15
X = 22
D = 4
H = 8
M = 12
R = 16
Z = 24
E = 5
J = 9
N = 13
T = 18
Driver:
(50 Hz, no single phase number 0, 1, 4)
1 = 1PH ODP
5 = 3PH TEFC
9 = 3PH TEFC
with premium effi ciency
2 = 3PH ODP
6 = 575V TEFC
0 = 1PH XP
3 = 575V ODP
7 = 3PH XP
4 = 1PH TEFC
8 = 575V XP
HP Rating:
C = ½ F = 1½ J = 5
M = 15
D = ¾ G = 2
K = 7½ N = 20
E = 1
H = 3
L = 10
P = 25
Hertz/RPM:
1 = 60 Hz/3500 RPM
4 = 50 Hz/2900 RPM, 460 V
2 = 50 Hz/2900 RPM, 190-380 V, (50 Hz motor)
5 = 60 Hz/3500 RPM, 220-380 V, D.O.L.
3 = 60 Hz/3500 RPM, 380 V
6 = 60 Hz/3500 RPM, 380 V, Y-DELTA
Material and Suction/Discharge:
A = 304 stainless steel, in-line NPT threaded oval fl ange connections (1, 2, 3 only)
B = 304 stainless steel, in-line ANSI fl ange (1, 2, 3, 4SV)
C = 304 stainless steel, top/bottom ANSI fl ange connections
D = 316 stainless steel, in-line ANSI fl ange
Product Line: Stainless Vertical
Nominal Flow:
1 = 15 GPM
3 = 55 GPM
2 = 28 GPM
4 = 86 GPM
Always specify the unit model and catalog number from pump nameplate when service or
technical assistance is required.
NOTICE: INSPECT UNIT FOR DAMAGE AND REPORT ALL DAMAGE TO THE CARRIER
OR DISTRIBUTOR/DEALER IMMEDIATELY.
➤
Code No.
Rotary
Stationary
Elastomer
Reference Application
0
High
Duty
Viton General
Service
Carbon
2
Silicon
Carbide
EPR Boiler
Feed
Graphite
Filled
4
Silicon
Carbide
Viton Abrasive
Graphite
Filled
6
High
Duty
EPR High
Temperature
Carbon
Silicon
Carbide
Graphite
Filled
