6
SECTION 2: SYSTEM COMPONENTS
Please review the SPD Plus Variable Speed Pump Controller components and ensure that you have all the parts
and are familiar with their names. Be sure to inspect all components supplies for shipping damage.
SPD Plus Variable Speed Pump Controller Package:
• SPD Plus Variable Speed Controller
• Pressure Transducer with Cable
• Output Reactor (if ordered)
• Installation and Operation Manual
WARNING
DO NOT
power the unit or run the pump until all electrical and plumbing connections,
especially the pressure sensor connection, are completed. The pump should not be run dry.
All electrical work must be performed by a qualified technician. Always follow the National
Electrical Code (NEC), or the Canadian Electrical Code (CEC) as well as all local, state and
provincial codes. Code questions should be directed to your local electrical inspector or code
enforcement agency. Failure to follow electrical codes and OSHA safety standards may result in
personal injury or equipment damage. Failure to follow manufacturer's installation instructions
may result in electrical shock, fire hazard, personal injury, death, damage to equipment, unsatisfactory
performance and may void manufacturer's warranty.
WARNING
Hazardous
voltage
Hazardous
Pressure
CAUTION
SPD PLUS TYPE CODE AND PART NUMBER
Type Code:
SPD 4 0600 N1
Enclosure and Filter Options
Blank = NEMA 3R, no filter
F = NEMA 3R, with filter
N1 = NEMA 1, no filter
Nominal Horsepower
0400 = 40 HP
0500 = 50 HP
0600 = 60 HP
0750 = 75 HP
1000 = 100 HP
Voltage
2 = 230V
4 = 460V
5 = 575V
Single Pump Drive
NOTE: HP rating is for reference only, and is based on 3Ø input power.
