Pièces de rechange (suite) – Xylem IM191 R03 Marlow Series Prime Line Self-Priming Centrifugal Pumps User Manual
Page 48
48
N
o
Description N
o
Description N
o
Description
1 Corps de pompe 37
Clavette de roue 96
Joint plat poinçonné
2 Bouchon fileté 38
Arbre 106
Anneau élastique
4 Écrou autofreiné de roue 39
Clavette d’accouplement 107
Cale de roulement
5 Rondelle courbée de roue 42
Joint à lèvres 108
Anneau élastique
7 Joint torique 44
Rondelle-frein 109
Joint torique
8 Joint plat poinçonné 45
Vis de rapprochement 110
Porte-roulement
10 Logement de garniture mécanique 46
Diffuseur 111
Contre-écrou hexagonal
17 Garniture mécanique 49
Joint plat poinçonné 112
Vis d’écartement
27 Bouchon fileté 50
Tubulure d’aspiration 117
Roulement à billes arrière
28 Bouchon fileté 51
Clapet de non-retour 118
Vis à épaulement
29 Lubrificateur à huile (en option) 53
Plaquette de retenue (clapet) 130
Plaque d’adaptation
30 Reniflard à filtre 63
Déflecteur de liquide 132
Couvercle de pompe
31 Corps de palier 67
Adaptateur (corps de palier) 133
Vis d’assemblage
35 Patte de fixation 91
Roue ouverte 134
Rondelle-frein
36 Roulement à billes avant 93
Joint plat poinçonné
50 51 53 118
93
132
111
112
42
38
39
27
108
107
45
44
35
7 46 37 91
10
1
96
67
42
27
36
30
31
130
117 109 110
106
2
4
133 134
8
5
49
63
27
29, 27 28
28
17
Pièces de rechange (suite)
COUPE DES PRIME LINE SUR PALIER — 4E ET 6E
