SAFETY INSTRUCTIONS

TO AVOID SERIOUS OR FATAL PERSONAL IN-

JURY OR MAJOR PROPERTY DAMAGE, READ

AND FOLLOW ALL SAFETY INSTRUCTIONS IN

MANUAL AND ON PUMP.
THIS MANUAL IS INTENDED TO ASSIST IN THE

INSTALLATION AND OPERATION OF THIS UNIT

AND MUST BE KEPT WITH THE PUMP.
THOROUGHLY REVIEW ALL INSTRUCTIONS

AND WARNINGS PRIOR TO PERFORMING ANY

WORK ON THIS PUMP.
MAINTAIN ALL SAFETY DECALS.

This is a SAFETY ALERT SYMBOL.

When you see this symbol on the pump

or in the manual, look for one of the

following signal words and be alert

to the potential for personal injury or

property damage.
Warns of hazards that WILL cause

serious personal injury, death or major

property damage.
Warns of hazards that CAN cause

serious personal injury, death or major

property damage.
Warns of hazards that CAN cause per-

sonal injury or property damage.

NOTICE: INDICATES SPECIAL INSTRUCTIONS

WHICH ARE VERY IMPORTANT AND

MUST BE FOLLOWED.

PUMPING HAZARDOUS LIQUIDS

OR FLAMMABLE GASES CAN

CAUSE FIRE, BURNS OR DEATH.

DESCRIPTION AND SPECIFICATIONS

Assembled pump/motor units purchased from the factory

are UL

®

and CSA listed. ALL Franklin Electric motors are

UL

®

recognized and CSA listed.

INSPECT UNIT FOR DAMAGE AND REPORT ALL

DAMAGE TO THE CARRIER IMMEDIATELY.

IMPORTANT PRECAUTIONS

All electrical work must be performed by a qualified

technician. Always follow the National Electrical Code

(NEC), or the Canadian Electrical Code, as well as all

local, state and provincial codes. Code questions should

be directed to your local electrical inspector. Failure to

follow electrical codes and OSHA safety standards may

result in personal injury or equipment damage. Failure to

follow manufacturer’s installation instructions may result

in electrical shock, fire hazard, personal injury or death,

damaged equipment, provide unsatisfactory performance,

and may void manufacturer’s warranty.

DANGER

WARNING

CAUTION

WARNING

Hazardous fluids

can cause fire,

burns or death.

DANGER

Table of Contents

SUBJECT

PAGE

Safety Instructions ................................................. 2
Description and Specifications ............................... 2
Important Precautions ........................................... 2
Piping .................................................................... 2
Wiring and Grounding .......................................... 2
Motor Cable Installations ...................................... 3
Pump Installation .................................................. 4
Tank with effluent filter ......................................... 4
Troubleshooting .................................................... 5
Motor Insulation Resistance Readings ................... 5

Owner’s Information

Please fill in information and give this booklet to

homeowner.
Model Number:

Serial Number:
Dealer:
Dealer’s Phone No.
Date of Purchase:

Installation:
