The table below indicates the functions of the audio jacks on the rear panel:
Note: See "Connecting peripherals" on page 7.
Parallel/printer port
External display port
USB ports
Network port
Audio jacks
Expansion slots
Chassis lock
DVI port (for selected models only)
Color/use Headphone 1.1 CH 3.1 CH 5.1 CH 7.1 CH
Blue
Line-in Line-in Line-in Line-in Line-in
Green
Headphone Line-out Front Front Front
Pink
Mic-in Mic-in Mic-in Mic-in
Orange Rear Rear
Black Center/
woofer Center/
woofer Center/
woofer
Gray Side
Icon Description
