Table 1. DC Volume Control
Step Gain (dB) Step Gain (dB)
0 -75 32 11.6
1 -40 33 12.0
2 -34 34 12.4
3 -28 35 12.8
4 -22 36 13.2
5 -16 37 13.6
6 -10 38 14.0
7 -7.5 39 14.4
8 -5.0 40 14.8
9 -2.5 41 15.2
10 0 42 15.6
11 1.5 43 16.0
12 3.0 44 16.4
13 4.0 45 16.8
14 4.4 46 17.2
15 4.8 47 17.6
16 5.2 48 18.0
17 5.6 49 18.4
18 6.0 50 18.8
19 6.4 51 19.2
20 6.8 52 19.6
21 7.2 53 20.0
22 7.6 54 20.4
23 8.0 55 20.8
24 8.4 56 21.2
25 8.8 57 21.6
26 9.2 58 22.0
27 9.6 59 22.4
28 10.0 60 22.8
29 10.4 61 23.2
30 10.8 62 23.6
31 11.2 63 24.0
