Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter Symbol Test Conditions Min Typ Max Units
Input Voltage Range V
INDC
DC Input Voltage 12 500 V
Shutdown Mode Supply Current I
INSD
Pin PWMD to GND 0.1 mA
Internally Regulated Voltage V
DD
V
IN
> 20V 6 10 V
Current Sense Pul-In Threshold Voltage V
CS,TH
250 mV
Current Sense Blanking Interval T
BLANK
250 Ns
Gate Sourcing Current I
SOURCE
V
GATE
= 0V 0.2 A
Gate Sinking Current I
SINK
V
GATE
= V
DD
0.2 A
Gate Output Rise Time t
RISE
C
GATE
= 1nF 30 50 ns
Gate Output Fall Time t
TALL
C
GATE
= 1nF 30 50 ns
Oscillator Frequency f
OSC
R
T
= 510kΩ 37 41 49
kHz
R
T
= 226kΩ 74 92 110
EN Threshold High V
EH
V
IN
= 12V to 500V 2.4 V
EN Threshold Low V
EL
V
IN
= 12V to 500V 1.0 V
Over Temperature Protection OTP 160 °C
OTP Hysteresis OTH 50 °C
