Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating Unit
Input Voltage -0.3 to +6.0 V
EN, FB Pin Voltage -0.3 to V
IN
V
SW Pin Voltage -0.3 to (V
IN
+0.3) V
Junction Temperature 150 °C
Storage Temperature Range -65 to +150 °C
Soldering Temperature 300, 5sec °C
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Supply Voltage 2.5 to 5.5 V
Operation Temperature Range -40 to +85
°C
Junction Temperature Range -40 to +125
Thermal Information
Parameter Package Symbol Max Unit
Thermal Resistance (Junction to Case)
TSOT25 (Note 1)
θ
JC
130
°C/W
DFN2x2-6 25
QFN3x3-16 14
Thermal Resistance (Junction to Ambient)
TSOT25
θ
JA
250
DFN2x2-6 68
QFN3x3-16 35
Internal Power Dissipation
TSOT25
P
D
400
mW DFN2x2-6 980
QFN3x3-16 1470
Note: 1. The maximun output current for TSOT25 package is limited by internal power dissipation capacity as described in
Application Information here inafter.
