Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground
Parameter Rating Unit
Input Voltage -0.3 to +6.0 V
EN, FB Pin Voltage -0.3 to V
IN
V
SW Pin Voltage -0.3 to (V
IN
+0.3) V
Junction Temperature 150 °C
Storage Temperature Range -65 to +150 °C
Soldering Temperature 300, 5 sec °C
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Supply Voltage 2.7 to 5.5 V
Operation Temperature Range -40 to +85
°C
Junction Temperature Range -40 to +125
Thermal Information
Parameter Symbol Package Max Unit
Thermal Resistance (Junction to Case) θ
JC
TSOT23-5 (Note 1) 130
°C/W
TDFN22-8 23.4
TDFN22-6 25
Thermal Resistance (Junction to Ambient) θ
JA
TSOT23-5 250
TDFN22-8 70
TDFN22-6 68
Internal Power Dissipation (T
A
= +25°C) P
D
TSOT23-5 400
mW TDFN22-8 1400
TDFN22-6 980
Note: 1. The maximun output current for TSOT23-5 package is limited by internal power dissipation capacity as
described in Application Information hereinafter.
