Diodes MMSTA14 - Manual (Page 2)

Electrical Characteristics
@T A = 25°C unless otherwise specified
Characteristic Symbol Min Max Unit Test Condition
OFF CHARACTERISTICS (Note 5)
Collector-Emitter Breakdown Voltage
V
(BR)CEO
30 ⎯ V I
C
= 100 μA V
BE
= 0V
Collector Cutoff Current I
CBO
⎯ 100 nA V
CB
= 30V, I
E
= 0
Emitter Cutoff Current I
EBO
⎯ 100 nA V
EB
= 10V, I
C
= 0
ON CHARACTERISTICS (Note 5)
DC Current Gain MMSTA13
MMSTA14
MMSTA13
MMSTA14
h
FE
5,000
10,000
10,000
20,000
⎯ ⎯
I
C
= 10mA, V
CE
= 5.0V
I
C
= 10mA, V
CE
= 5.0V
I
C
= 100mA, V
CE
= 5.0V
I
C
= 100mA, V
CE
= 5.0V
Collector-Emitter Saturation Voltage V
CE(SAT)
⎯ 1.5 V I
C
= 100mA, I
B
= 100 μA
Base-Emitter Saturation Voltage V
BE(SAT)
⎯ 2.0 V I
C
= 100mA, V
CE
= 5.0V
SMALL SIGNAL CHARACTERISTICS
Output Capacitance C
obo
8.0 Typical pF V
CB
= 10V, f = 1.0MHz, I
E
= 0
Input Capacitance C
ibo
15 Typical pF V
EB
= 0.5V, f = 1.0MHz, I
C
= 0
Current Gain-Bandwidth Product f
T
125 ⎯ MHz
V
CE
= 5.0V, I
C
= 10mA,
f = 100MHz
Note: 5. Short duration pulse test used to minimize self-heating effect.
0
50
25 50 75 100 125 150 175 200
P
,
P
O
WE
R
DISS
IP
A
T
IO
N
(m
W
)
D
T , AMBIENT TEMPERATURE (°C)
Fig. 1, Max Power Dissipation vs. Ambient Temperature
A
100
150
200
0 1 10 100 1,000
V,
C
O
LL
E
C
T
O
R
T
O
EM
IT
T
E
R
SA
TURA
TI
O
N
VO
L
T
AG
E
(V)
CE
(S
A
T
)
I , COLLECTOR CURRENT (mA)
Fig. 2, Collector Emitter Saturation Voltage vs. Collector Current
C
T = 25°C
A
T = -50°C
A
T = 150°C
A
0.45
0.40
0.50
0.55
0.60
0.65
0.70
0.75
0.80
0.85
0.90
0.95
1.10
1.05
1.00
I
I
C
B
= 1000
100
1,000
100,000
1,000,000
10,000
1 10 1,000 100
h,
D
C
C
U
R
R
E
N
T
G
AI
N
FE
I , COLLECTOR CURRENT (mA)
Fig. 3, DC Current Gain vs. Collector Current
C
0.1 1 10 100
V
, BASE
E
M
IT
T
E
R
V
O
L
T
A
G
E (
V)
BE
(O
N
)
I , COLLECTOR CURRENT (mA)
Fig. 4, Base Emitter Voltage vs. Collector Current
C
T = 25°C
A
T = -50°C
A
T = 150°C
A
0.3
0.2
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.6
1.5
1.4
V = 5V
CE
DS30165 Rev. 9 - 2 2 of 3
www.diodes.com
MMSTA13/MMSTA14
© Diodes Incorporated
