ZXTR1005PD8
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(Voltage relative to GND, @ T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Input voltage V
IN
-0.3 to +100 V
Enable current I
EN
±1 mA
Continuous Input & Output Current I
IN
, I
OUT
100 mA
Peak Pulsed Input & Output Current I
IM
, I
OM
100 mA
Maximum Voltage applied to V
OUT
V
OUT(max)
10 V
Maximum Current
(@ V
IN
= 48V, T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Continuous Output Current (Note 7) I
OUT
42 mA
Pulsed Output Current
(Note 8)
I
OM
100
mA
(Note 9) 100
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 5)
P
D
1.84
W
(Note 6) 0.94
Thermal Resistance, Junction to Ambient
(Note 5)
R
θJA
54.3
°C/W
(Note 6) 106.4
Thermal Resistance, Junction to Lead (Note 10) R
θJL
13
Thermal Resistance, Junction to Case (Note 10) R
θJC
13.9
Maximum Operating Junction Temperature Range T
J
-55 to +125 °C
Storage Temperature Range T
STG
-65 to +150 °C
ESD Ratings
(Note 11)
Characteristics Symbols Value Unit JEDEC Class
Electrostatic Discharge – Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge – Machine Model ESD MM 400 V C
Notes: 5. For a device mounted with the exposed V
IN
pad on 50mm x 50mm 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is
measured under still air conditions whilst operating in steady-state.
6. Same as note 5, except mounted on 15mm x 15mm 1oz copper.
7. Same as note 5, whilst operating at V
IN
= 48V this is thermally limited. Refer to Safe Operating Area for other Input Voltages.
8. Same as note 5, except measured with a single pulse width = 100µs and V
IN
= 48V. This is limited by the absolute maximum I
OM
rating.
9. Same as note 5, except measured with a single pulse width = 10ms and V
IN
= 48V. This is limited by the absolute maximum I
OM
rating.
10. R ΘJL = Thermal resistance from junction to solder-point (on the exposed V
IN
pad).
R
ΘJC
= Thermal resistance from junction to the top of case.
11. Refer to JEDEC specification JESD22-A114 and JESD22-A115 .
