ZXTP2029F
© Zetex Semiconductors plc 2007
Electrical characteristics (at T
amb
= 25°C unless otherwise stated)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Conditions
Collector-base breakdown
voltage
V
(BR)CBO
-130
-160
V
I
C
=-100
μA
Collector-emitter breakdown
voltage
V
(BR)CEV
-130
-160
V
I
C
=
−1μA, 1V> V
BE
>-0.3V
Collector-emitter breakdown
voltage
V
(BR)CEO
-100
-120
V
I
C
=-10mA
(a)
NOTES:
(a) Measured under pulsed conditions. Pulse width=300
S. Duty cycle Յ2%.
Emitter-base breakdown
voltage
V
(BR)EBO
-7.0
-8.3
V
I
E
=-100
μA
Collector-emitter cut-off
current
I
CEV
-20
nA
V
CE
=-100V,
V
BE
= 1V
Collector-base cut-off current I
CBO
-20
nA
V
CB
=-100V
Emitter-base cut-off current
I
EBO
-10
nA
V
EB
=-6V
Static forward current
transfer ratio
H
FE
100
100
40
220
200
75
300
I
C
=-10mA, V
CE
I
C
=-1A, V
CE
=-2V
Ic=-3A, V
CE
=-2V
Collector-emitter saturation
voltage
V
CE(sat)
-20
-60
-135
-180
-30
-80
-180
-250
mV
mV
mV
mV
I
C
=-100mA, I
B
=-10mA
I
C
=-1A, I
B
=-100mA
I
C
=-3A, I
B
=-300mA
I
C
=-4A, I
B
=-400mA
Base-emitter saturation
voltage
V
BE(sat)
-0.90
-1.00
V
I
C
=-3A, I
B
=-300mA
Base-emitter turn-on voltage
V
BE(on)
-0.81
-0.90
V
I
C
=-3A, V
CE
=-2V
Transition frequency
f
T
150
MHz
Ic=-100mA, V
CE
=-10V,
f=50MHz
Output capacitance
C
obo
39
pF
V
CB
=-10V, f=1MHz
Delay timetime
t
(d)
21
ns
V
CC
=-10V, I
C
=-1A,
I
B1
=I
B2
=-100mA
Rise time
t
(r)
12
ns
Storage time
t
(stg)
410
ns
Fall time
t
(f)
35
ns
