DS30636 Rev. 4 - 2 2 of 4 MMDT3904VC
www.diodes.com
Electrical Characteristics @ T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Max Unit Test Condition
OFF CHARACTERISTICS (Note 6)
Collector-Base Breakdown Voltage V
(BR)CBO 60 ¾ V I
C
= 10mA, I
E
= 0
Collector-Emitter Breakdown Voltage V
(BR)CEO
40 ¾ V I
C
= 1.0mA, I
B
= 0
Emitter-Base Breakdown Voltage V
(BR)EBO 5.0 ¾ V I
E
= 10mA, I
C
= 0
Collector Cutoff Current I
CEX ¾ 50 nA V
CE
= 30V, V
EB(OFF)
= 3.0V
Base Cutoff Current I
BL ¾ 50 nA V
CE
= 30V, V
EB(OFF)
= 3.0V
ON CHARACTERISTICS (Note 6)
DC Current Gain h
FE
40
70
100
60
30
¾
¾
300
¾
¾
¾
I
C
= 100µA, V
CE
= 1.0V
I
C
= 1.0mA, V
CE
= 1.0V
I
C
= 10mA, V
CE
= 1.0V
I
C
= 50mA, V
CE
= 1.0V
I
C
= 100mA, V
CE
= 1.0V
Collector-Emitter Saturation Voltage V
CE(SAT) ¾
0.20
0.30
V
I
C
= 10mA, I
B
= 1.0mA
I
C
= 50mA, I
B
= 5.0mA
Base-Emitter Saturation Voltage V
BE(SAT)
0.65
¾
0.85
0.95
V
I
C
= 10mA, I
B
= 1.0mA
I
C
= 50mA, I
B
= 5.0mA
SMALL SIGNAL CHARACTERISTICS
Output Capacitance C
obo ¾ 4.0 pF V
CB
= 5.0V, f = 1.0MHz, I
E
= 0
Input Capacitance C
ibo ¾ 8.0 pF V
EB
= 0.5V, f = 1.0MHz, I
C
= 0
Input Impedance h
ie
1.0 10 kW
V CE = 10V, I C = 1.0mA,
f = 1.0kHz
Voltage Feedback Ratio h
re 0.5 8.0 x 10 -4
Small Signal Current Gain h
fe
100 400 ¾
Output Admittance h
oe 1.0 40 m S
Current Gain-Bandwidth Product f
T 300 ¾ MHz
V
CE
= 20V, I
C
= 10mA,
f = 100MHz
Noise Figure NF ¾ 5.0 dB
V
CE
= 5.0V, I
C
= 100mA,
R
S
= 1.0kW, f = 1.0kHz
SWITCHING CHARACTERISTICS
Delay Time t
d ¾ 35 ns V
CC
= 3.0V, I
C
= 10mA,
V
BE(off)
= - 0.5V, I
B1
= 1.0mA
Rise Time t
r ¾ 35 ns
Storage Time t
s ¾ 200 ns V
CC
= 3.0V, I
C
= 10mA,
I
B1
= I
B2
= 1.0mA
Fall Time t
f ¾ 50 ns
Notes: 6. Short duration test pulse used to minimize self-heating.
Month Jan Feb March Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Date Code Key
Marking Information
APK = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: R = 2004
M = Month ex: 9 = September
APK YM
Year 2005 2006 2007 2008 2009 2010 2011 2012
Code S T U V W X Y Z
