MMDT3904VC
DUAL NPN SMALL SIGNAL SURFACE MOUNT
TRANSISTOR
·
Epitaxial Planar Die Construction
·
Ideal for Low Power Amplification and Switching
·
Ultra-Small Surface Mount Package
·
Lead Free By Design/RoHS Compliant (Note 4)
·
"Green Device" (Note 5)
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
60
V
Collector-Emitter Voltage
V
CEO
40
V
Emitter-Base Voltage
V
EBO
6.0
V
Collector Current - Continuous
I
C
200
mA
Power Dissipation (Note 2)
P
d
200
mW
Thermal Resistance, Junction to Ambient
R
q
JA
625
°
C/W
Operating and Storage Temperature Range
T
j
, T
STG
-55 to +150
°
C
Features
Maximum Ratings
@ T
A
= 25°C unless otherwise specified
Mechanical Data
·
Case: SOT-563
·
Case Material: Molded Plastic, “Green” Molding
Compound. UL Flammability Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish - Matte Tin annealed over Copper
leadframe. Solderable per MIL-STD-202, Method 208
·
Terminal Connections: See Diagram
·
Marking (See Page 2): APK
·
Ordering Information: See Below
·
Date Code Information: See Page 2
·
Weight: 0.003 grams (approximate)
Device
Packaging
Shipping
MMDT3904VC-7
SOT-563
3000/Tape & Reel
Ordering Information
(Note 3)
C
1
B
2
E
2
C
2
E
1
B
1
SEE NOTE 1
A
M
L
B C
H
K
G
D
C
1
B
2
E
2
C
2
E
1
B
1
SOT-563
Dim
Min
Max
Typ
A
0.15
0.30
0.25
B
1.10
1.25
1.20
C
1.55
1.70
1.60
D
0.50
G
0.90
1.10
1.00
H
1.50
1.70
1.60
K
0.56
0.60
0.60
L
0.10
0.30
0.20
M
0.10
0.18
¾
All Dimensions in mm
Notes:
1. Package is non-polarized. Parts may be on reel in orientation illustrated, 180° rotated, or mixed (both ways).
2. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout
document AP02001, which can be found on our website 4. No purposefully added lead.
