Diodes MMDT2222V User Manual

Mmdt2222v, New p roduct, Features maximum ratings

background image

Lead-free Green

DS30563 Rev. 4 - 2

1 of 4

MMDT2222V

www.diodes.com

ã

Diodes Incorporated

·

Epitaxial Planar Die Construction

·

Complementary PNP Type Available
(MMDT2907V)

·

Ultra-Small Surface Mount Package

·

Lead Free By Design/RoHS Compliant (Note 1)

·

"Green" Device (Note 2)

·

Qualified to AEC-Q101 Standards for High Reliability

Features

Maximum Ratings

@ T

A

= 25

°C unless otherwise specified

A

M

L

B C

H

K

G

D

Mechanical Data

MMDT2222V

DUAL NPN SMALL SIGNAL SURFACE MOUNT TRANSISTOR

Characteristic

Symbol

Value

Unit

Collector-Base Voltage

V

CBO

75

V

Collector-Emitter Voltage

V

CEO

40

V

Emitter-Base Voltage

V

EBO

6.0

V

Collector Current - Continuous

I

C

600

mA

Operating and Storage and Temperature Range

T

j

, T

STG

-55 to +150

°C

SOT-563

Dim

Min

Max

Typ

A

0.15

0.30

0.25

B

1.10

1.25

1.20

C

1.55

1.70

1.60

D

0.50

G

0.90

1.10

1.00

H

1.50

1.70

1.60

K

0.56

0.60

0.60

L

0.10

0.30

0.20

M

0.10

0.18

¾

All Dimensions in mm

C

1

B

2

E

2

C

2

E

1

B

1

NEW

P

RODUCT

Notes:

1. No purposefully added lead.

2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout

document AP02001, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.

·

Case: SOT-563, Molded Plastic

·

Case Material: Molded Plastic, “Green” Molding
Compound. UL Flammability Classification Rating 94V-0

·

Moisture sensitivity: Level 1 per J-STD-020C

·

Terminal Connections: See Diagram

·

Terminals: Finish

¾ Matte Tin annealed over Copper

leadframe. Solderable per MIL-STD-202, Method 208

·

Polarity: See Diagrams Below

·

Marking & Type Code Information: See Last Page

·

Ordering Information: See Last Page

·

Weight: 0.003 grams (approx.)

Thermal Characteristics

@ T

A

= 25

°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Total Power Dissipation (Note 3)

P

d

150

mW

Thermal Resistance, Junction to Ambient (Note 3)

R

qJA

833

°C/W
