ZXTP25020CFF
© Zetex Semiconductors plc 2007
Electrical characteristics (at T
amb
= 25°C unless otherwise stated)
Parameter
Symbol
Min.
Typ.
Max.
Unit Conditions
Collector-base breakdown
voltage
BV
CBO
-25
-50
V
I
C
= -100
A
Collector-emitter breakdown
voltage (base open)
BV
CEO
-20
-35
V
I
C
= -10mA
(*)
NOTES:
(*) Measured under pulsed conditions. Pulse width
Յ300
s; duty cycle
Յ2%.
Emitter-base breakdown
voltage
BV
EBO
-7
-8.2
V
I
E
= -100
A
Emitter-collector breakdown
voltage (reverse blocking)
BV
ECX
-7
-8.0
V
I
E
= -100
A
BC
< 10k
⍀
or -0.25 < V
BC
<0.25V
Emitter-collector breakdown
voltage (base open)
BV
ECO
-7
-8.8
V
I
E
= -100uA
Collector-base cut-off current
I
CBO
<-1
-50
nA
V
CB
= -20V
-20
A V
CB
= -20V, T
amb
= 100°C
Emitter-base cut-off current
I
EBO
<-1
-50
nA
V
EB
= -5.6V
Collector-emitter saturation
voltage
V
CE(sat)
-50
-65
mV
I
C
= -1A, I
B
= -100mA
-80
-110
mV
I
C
= -1A, I
B
= -20mA
-135
-185
mV
I
C
= -2A, I
B
= -40mA
-210
-260
mV
I
C
= -4.5A, I
B
= -225mA
Base-emitter saturation voltage V
BE(sat)
-950
-1050
mV
I
C
= -4.5A, I
B
= -225mA
Base-emitter turn-on voltage
V
BE(on)
-840
-950
mV
I
C
= -4.5A, V
CE
= -2V
Static forward current transfer
ratio
h
FE
200
350
500
I
C
= -10mA, V
CE
= -2V
150
250
I
C
= -1A, V
CE
= -2V
85
140
I
C
= -4A, V
CE
= -2V
40
I
C
= -10A, V
CE
= -2V
Transition frequency
f
T
285
MHz I
C
= -50mA, V
CE
= -10V
f
= 100MHz
Output capacitance
C
obo
32.4
40
pF
V
CB
= -10V, f
= 1MHz
Delay time
t
d
38.4
ns
V
CC
= -15V.
I
C
= -750mA,
I
B1
= I
B2
= -15mA.
Rise time
t
r
49.2
ns
Storage time
t
s
168
ns
Fall time
t
f
55
ns
