MMBD3004A/C/S
Document number: DS30353 Rev. 13 - 2
2 of 4
www.diodes.com
April 2014
© Diodes Incorporated
MMBD3004A/C/S
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Repetitive Peak Reverse Voltage V
RRM
350 V
Working Peak Reverse Voltage
DC Blocking Voltage V
RWM
V
R
300 V
RMS Reverse Voltage V
R(RMS)
212 V
Forward Continuous Current (Note 6) I
F
225 mA
Peak Repetitive Forward Current (Note 6) I
FRM
625 mA
Non-Repetitive Peak Forward Surge Current @ t = 1.0µs
@ t = 1.0s
I
FSM
4.0
1.0
A
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 6) P
D
350 mW
Thermal Resistance Junction to Ambient Air (Note 6) R
θJA
357 C/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage (Note 7) V
(BR)R
350   V I
R
= 150μA
Forward Voltage V
F

0.78
0.93
1.03 0.87
1.0
1.25
V
I
F
= 20mA
I
F
= 100mA
I
F
= 200mA
Reverse Current (Note 7) I
R 
30
35 100
100 nA
μA V
R
= 240V
V
R
= 240V, T
J
= +150°C
Total Capacitance C
T
 1.0 5.0 pF V
R
= 0V, f = 1.0MHz
Reverse Recovery Time t
rr
  50 ns
I
F
= I
R
= 30mA,
I
rr
= 3.0mA, R
L
= 100Ω
Notes: 6. Part mounted on FR-4 substrate with pad dimensions 1 inch X 1 inch, 2oz, copper, single-sided, PC board.
7. Short duration pulse test used to minimize self-heating effect.
400
T , AMBIENT TEMPERATURE, (°C)
Figure 1 Power Derating Curve, Total Package
A
P
,
P
O
WE
R
DIS
S
IP
A
T
IO
N (
m
W
)
D
200
100
300
0
500
0 160 200 120 80 40
Note 6
I
, I
N
ST
A
N
TA
NE
OUS
F
O
R
W
A
R
D
CURRE
NT
(
A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
Figure 2 Typical Forward Characteristics, Per Element
F
0.00001
0.0001
0.001
0.01
0.1
1
10
0 300 600 900 1200 1500
